Rubber track undercarriage system with load capacity of 2 ton

Price:	2000.0~5000.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: KGRT-2000

Production Capacity: 500 setsper month

Delivery Date: 10 days

load capacity: 2000kgs

cell: 008618758373076

Means of Transport: Ocean,Land,Air

Packing: pallet

Brand Name: frances@bonnyhydraulic.com

contact: Ms.Frances

Skype: frances.ge

Rubber track undercarriage manufacturer
rubber track frame,rubber tracks,
crawler undercarriage

Model: RT series

Type: Rubber Tracks

Load Capacity: 0.8-20 Ton

Bonny hydraulics trasnsmission Co.,lTD tracked undercarriage factory, is specializedin the research and development of rubber and steel tracked undercarriage.

Since the establishment of Bonny Hydraulic, it keeps the whole world in view and blaze steadilynew trails. By now, we have developed various tracked undercarriage systems andthe load capacity is from 0.5 ton to 20 ton.

It has been widely applied indrilling machines (core drill, horizontal directional drilling rig, beltengineering drill, and engineering rig), engineering machines, mining, colliery,agricultural and gardening machines. Meanwhile, we have a lot of experienceengineers who can provide you technical support and technical consultancy tomeet your needs.

Features:

Adopt high strength engineering rubber track.

The track motor can be fixed displacement or variable displacement concealedplanetary gearbox and hydraulic motor, such as Nabtesco (Japen), Brevini(Italia). If you need, we can also provide track motor made by our ownfactory.

The beam is made of Q345B with high loading capacity.

It can also be designed and manufactured on customers' request.

Bonny hydraulic is a Chinese company specialized in the production of crawlerundercarriages, adjusting undercarriage of cranes, production of transportsystems and convayors and the production of steel constructions. We advise andassist in the design and development and construction of undercarriage .

Production of crawler undercarriages

- Extensive range of standard undercarriage fitted with rubber or steeltracks
- Custom made undercarriages
- Complete undercarriages with traveldrive:imported Korea dual speed travel drive

Engineering

Our development department designs, develops and calculates full trackundercarriages and track systems for various applications. The products arefully assembled according to customer wishes, where concepts such as quality,durability, functionality and cost center are main goals.

In addition todeveloping new concepts, existing standard products continuously improved anddeveloped, so that is always built according tothe latest requirements and itis equipped with modern components.

In its work, the engineeringdepartment uses modern 3D CAD applications and finite element packages, so theycan work quickly and effectively.

The following is our standard model for your reference,custom dimensionscan be achieved according to your requirements.
Rubber track undercarriage system with load capacity of 2 ton

MODEL	Dinamic capacity	Static capacity	Weight kg.	Press.Bar	oil flow L/min	Torque Nm to engine	Grad.	Speed km/h
KGRT-1500	1200	1500	330	270	17	2000	65%	1.7
KGRT-2500	2500	3000	380	220	35	4723	65%	2/3.2
KGRT-3500	3500	4000	650	220	35	4723	65%	2/3.5
KGRT-5000	5000	6000	900	220	55	8330	65%	2/3.7
KGRT-6000	6000	7000	1280	220	55	8330	65%	2/3.7
KGRT-8000	8000	9500	1550	300	82	11700	65%	2.8/4.7

MODEL	A Length	B Center Distance	C Height	D Total Width	E Width of track shoe	F Height of Cross beam	No. of roller
KGRT-1500	1420	1066	350	980	230	165	3+3
KGRT-2500	1850	1370	480	1220	250	245	4+4
KGRT-3500	1980	1511	500	1520	300	250	5+5
KGRT-5000	2500	1950	550	1800	350	265	6+6
KGRT-6000	2905	2355	550	1800	400	265	7+7
KGRT-8000	2950	2450	600	1800	400	310	7+7
